Electric Adjustable Diffusion Panel Godox AD33 K1 (3x3)

Godox AD33 K1: New motorized adjustable diffusion panel. Instantly adjust diffusion levels, smoothly transitioning from hard to ultra-soft light with precise motorized control, enabling dynamic diffusion effects. Availble in three sizes, its innovative flodable frame and velcro-mount design ensure easy transport and setup. Supports DMX, CRMX, Bluetooth and controller options, with multiple power solutions including a 20-hour runtime at full load on a 100Wh battery.

Motorized Diffusion Lighting Evolved:

Instantly adjust your diffusion level—smoothly and quickly shifting from hard shadows to ultra-soft illumination. Precise motorized control enables dynamic diffusion changes exactly when and how you need them, enhancing flexibility on set and expanding creative possibilities.

Flexible Power Solutions, Extended Runtime:

Powered via USB-C, V-mount batteries, or NPF batteries. Achieve up to 20 hours of continuous use at full load from a single 100Wh battery—covering even the longest shooting days.

Precision Dimming with Dual Modes:

Supports both Level Mode and Light Reduction Mode. Level Mode enables 0-100% visualized quick adjustments, providing intuitive diffusion control. Light Reduction Mode offers a -0.1 to -2.0 EV range, designed to match professional workflows.

Patented Frequency Adjustment Technology:

Features patented frequency adjustment technology, supporting five frequency levels to ensure flicker-free operation tailored to different frame rates. Compatible with frame rates up to 300fps.

Easy Storage:
The collapsible frame ensures compact storage and rapid deployment. A removable, Velcro-attached diffusion panel allows convenient storage and quick replacement, featuring IP54-rated protection for reliable all-weather shooting.

Versatile, Reliable Control:

Control it your way—both controllers support operation via controller, Bluetooth APP, and DMX. Additionally, the AD00-01 controller integrates a built-in CRMX transceiver, ensuring stable, low-latency wireless control. Lead/Follow mode lets one controller sync them all for smooth, unified adjustments on set.

Two Controller Options:

Each size of the adjustable diffusion panel offers two controller options, letting users choose based on their specific workflow and daily needs.

Technical specifications:

Model: AD33
Power:
USB-C port: input 5V=2A
AC port : 0V-25V~
Controlling method: DMX/RMD, Bluetooth APP, controller control
Distance: 30m
Dimension diffusion: 41.46" х 39.61" (105 x 100 cm)
Dimension Controller (AD00-02): 1.97" х 1.42" х 0.71 (5 x 3.6 x 1.8 cm)
Weight diffusion: 0.8kg.
Weight Controller: 0.16kg.
