Nanlite PavoSlim 240CL RGBWW light panel

Key features

• LED RGBWW Panel Light
• Super-thin metal body of 2.35cm
• Wide CCT range of 2700K-7500K, G/M ±150 adjustment
• Multiple lighting modes: CCT, HSI, RGBW, Gel, Efect
• 151 gels available, 15 built-in effects
• Multiple control methods
• Multiple power supply options: AC, DC, Battery
• 1/4"-20 thread in each corner for optional accessories
• Quick release plate and two holders for mounting and adjustment

Light, strong and efficient
PavoSlim panels combine a thin and strong metal body. Even with the PavoSlim mounting accessories and attached collapsible diffuser, it is still lighter and thinner than comparable flexible panels with attached mounting brackets. This makes it ideal for small studios with low ceilings, filming inside vehicles or demanding film and TV scenes.
Another distinctive feature of PavoSlim is the special optical system created for each individual LED chip. Combining efficient heat dissipation and excellent optical design, PavoSlims achieve 4x more power than similar products.
Ease of use
Every moment counts on set, so every element of PavoSlim is designed for quick deployment. There are multiple mounting slots on the back, a quick release plate and a strap designed to hang the control unit. All accessories are designed with the same quick setup philosophy, allowing users to effortlessly complete PavoSlim installation within a minute. The RGBWW PavoSlim 240CL provides CCT modes as well as additional HSI, RGBW and Gel modes. In HSI mode, hue, saturation and intensity can be quickly adjusted to achieve any one of 36,000 colors. In RGBW mode, there are controls for four separate channels - red, green, blue and white, allowing for greater color accuracy. In gel mode, the 240CL accurately reproduces the colors of 151 commonly used gels, conveniently eliminating the time, energy and expense of installing separate gel filters. As a result, the 240CL offers more possibilities for emotional expression and atmosphere.
Wide compatibility
Managing PavoSlim is easy. Two buttons, two knobs and a two-inch screen on the control unit give full control of the device. Control via the NANLINK app is just as easy, connecting via the built-in 2.4G and Bluetooth modules. All PavoSlim panels also have wired DMX/RDM to allow integration with standard film and TV control systems, making implementing lighting effects easy. The PavoSlim 240CL are also equipped with LumenRadio CRMX, which enables wireless DMX/RDM control. This allows the panels to connect effectively with a variety of other lighting fixtures on set, combining stability with flexibility.
Multiple power options
The PavoSlim has multiple power options that support full power output, making it excellent for both indoor and outdoor scenarios. The PavoSlim 240B and 240CL have the option of mains powered, V-mount batteries that attach directly to the control unit.Multiple power options
The PavoSlim has multiple power options that support full power output, making it excellent for both indoor and outdoor scenarios. The PavoSlim 240B and 240CL have the option to be powered by mains, V-mount batteries that attach directly to the control unit.
AC Power: AC 100-240V 50/60HZ
DC power supply: DC 48V/5.6A
Battery powered
14.4-14.8V V-mount battery ×1: 50% of maximum power
14.4-14.8V V-mount battery ×2: full power
26V V-mount battery ×1: 80% of maximum power
26V V-mount battery ×2: full power
14.4-14.8 V V-mount battery × 1 and 26 V V-mount battery × 1: full power
Flexible installation for any situation
Several additional accessories have also been developed exclusively for the PavoSlim series. A set of 1/4"-20 threaded magnetic adapters screw to each corner of the PavoSlim, providing a quick and strong magnetic mount. Two PavoSlim panels of the same size can be clamped together to form a larger source using the set for connecting two PavoSlims.These are brackets that support both horizontal and vertical connection using the mounting holes on the back of the body.A 2.6m extension cable and two types of softboxes are also available.
Specs
Rated Power: 260W
Input Voltage/Current AC 100-240V 50/60HZ, DC 48V/5.6A, DC (Battery) 14.4-26V
Beam Angle: 60°
Dimming: 0-100%
CCT: 2700K-7500K (GM±150)
CRI: Average 96
TLCI: Average 97
TM-30 Rf: Average 94
TM-30 Rg: Average 100
Control: On-board, Remote Controller, NANLINK APP, DMX/RDM, LumenRadio CRMX
Photometrics
Light Only
2700K: 0.5m - 40650 lux/3776 fc; 1m - 17690 lux/1643 fc;    3m - 2888 lux 268 fc;
3200K: 0.5m - 44520 lux/4136 fc; 1m - 19570 lux/1818 fc;    3m - 3153 lux 293 fc;
5600K: 0.5m - 48180 lux/4476 fc; 1m - 21030 lux/1954 fc;    3m - 3404 lux 316 fc;
6500K: 0.5m - 47530 lux/4416 fc; 1m - 20760 lux/1929 fc;    3m - 3368 lux 313 fc;
R: 0.5m - 20520 lux/1906 fc; 1m - 8350 lux/776 fc; 3m - 1267 lux 118 fc;
G: 0.5m - 37620 lux/3495 fc; 1m - 15570 lux/1446 fc; 3m - 2240 lux 208 fc;
B: 0.5m - 6940 lux/645 fc; 1m - 1900 lux/177 fc; 3m - 273 lux 25 fc;
With Softbox and Lite Diffuser
2700K: 0.5m - 26200 lux/2434 fc; 1m - 9140 lux/849 fc; 3m - 1255 lux/117 fc;
3200K: 0.5m - 28930 lux/2688 fc; 1m - 10070 lux/936 fc; 3m - 1375 lux/128 fc;
5600K: 0.5m - 31470 lux/2924 fc; 1m - 10850 lux/1008 fc; 3m - 1483 lux/138 fc;
6500K: 0.5m - 31040 lux/2884 fc; 1m - 10550 lux/980 fc; 3m - 1471 lux/137 fc;
R: 0.5m - 13350 lux/1240 fc; 1m - 4690 lux/436 fc; 3m - 655 lux/61 fc;
G: 0.5m - 25430 lux/2362 fc; 1m - 8644 lux/803 fc; 3m - 1171 lux/109 fc;
B: 0.5m - 3240 lux/301 fc; 1m - 1100 lux/102 fc; 3m - 145 lux/13 fc;
With Softbox and Standard Diffuser
2700K: 0.5m - 15710 lux/1459 fc; 1m - 4678 lux/435 fc; 3m - 604 lux/56 fc;
3200K: 0.5m - 17310 lux/1608 fc; 1m - 5149 lux/478 fc; 3m - 664 lux/62 fc;
5600K: 0.5m - 18650 lux/1733 fc; 1m - 5571 lux/518 fc; 3m - 720 lux/67 fc;
6500K: 0.5m - 18420 lux/1711 fc; 1m - 5502 lux/511 fc; 3m - 713 lux/66 fc;
R: 0.5m - 8190 lux/761 fc; 1m - 2391 lux/222 fc; 3m - 330 lux/31 fc;
G: 0.5m - 15390 lux/1430 fc; 1m - 4631 lux/430 fc; 3m - 598 lux/56 fc;
B: 0.5m - 2060 lux/191 fc; 1m - 620 lux/58 fc; 3m - 79 lux/7 fc;
With Softbox, Lite Diffuser and Eggcrate
2700K: 0.5m - 15980 lux/1485 fc; 1m - 6939 lux/645 fc; 3m - 1075 lux/100 fc;
3200K: 0.5m - 17750 lux/1649 fc; 1m - 7651 lux/711 fc; 3m - 1178 lux/109 fc;
5600K: 0.5m - 19240 lux/1787 fc; 1m - 8276 lux/769 fc; 3m - 1273 lux/118 fc;
6500K: 0.5m - 18920 lux 1758 fc; 1m - 8110 lux/753 fc; 3m - 1262 lux/117 fc;
R: 0.5m - 7900 lux/734 fc; 1m - 3510 lux/326 fc; 3m - 572 lux/53 fc;
G: 0.5m - 15340 lux/1425 fc; 1m - 6590 lux/612 fc; 3m - 1003 lux/93 fc;
B: 0.5m - 1950 lux/181 fc; 1m - 840 lux/78 fc; 3m - 124 lux/12 fc;
With Softbox, Standard Diffuser and Eggcrate
2700K: 0.5m - 8848 lux/822 fc; 1m - 3540 lux/329 fc; 3m - 498 lux/46 fc;
3200K: 0.5m - 9860 lux/916 fc; 1m - 3903 lux/363 fc; 3m - 547 lux/51 fc;
5600K: 0.5m - 10690 lux/993 fc; 1m - 4220 lux/392 fc; 3m - 592 lux/55 fc;
6500K: 0.5m - 10550 lux/980 fc; 1m - 4165 lux/387 fc; 3m - 584 lux/54 fc;
R: 0.5m - 4650 lux/432 fc; 1m - 1911 lux/178 fc; 3m - 276 lux/26 fc;
G: 0.5m - 8842 lux/821 fc; 1m - 3505 lux/326 fc; 3m - 490 lux/46 fc;
B: 0.5m - 1180 lux/110 fc; 1m - 470 lux/44 fc; 3m - 65 lux/6 fc;
