Name: RED KOMODO X 6K
Brand: Red Digital Cinema
SKU: 710-0356
Price: 16221.00 EUR
Availability: OutOfStock

RED KOMODO X 6K

Price

6 910.15 EUR excl VAT

Availability:

Code: 710-0356

Usualy ships within 25 days

Availability notification

Please fill your E-mail address where you want to receive the availability notification for RED KOMODO X 6K or your contact phone number.

Description Specification Package Related Products

RED further advances its KOMODO line with the release of the black KOMODO-X 6K, a digital cinema camera featuring faster frame rates, a redesigned S35 sensor, and an updated form including advanced video and audio interfaces. With built-in Wi-Fi and a USB-C connector, the KOMODO-X provides a powerful platform for smooth professional capture, multicamera setups, and IP-based workflows, including live streaming. The KOMODO-X will be complemented by pre-bundled packs and additional accessories such as RED Pro I/O V-Mount and Gold Mount Modules.

Imaging

Lens Mount	Canon RF
Lens Communication	Yes, with Autofocus Support
Sensor Resolution	Effective: 19.9 Megapixel (6144 x 3240)
Image Sensor	27.03 x 14.26 mm (Super35) CMOS
Image Stabilization	None
Built-In ND Filter	None
Capture Type	Stills & Video

Exposure Control

Shutter Type	Electronic Global Shutter
Advertised Dynamic Range	16.5 Stops

Video Capture

Internal Recording Modes	ProRes 4444XQ 4:4:4 4096 x 2160 up to 60.00 fps [560 MB/s] ProRes 4444 4:4:4 4096 x 2160 up to 80 fps [560 MB/s] ProRes 422/ProRes 422 HQ/ProRes 422LT 4096 x 2160 up to 120 fps [560 MB/s] REDCODE RAWREDCODE HQ/REDCODE LQ/REDCODE MQ 6144 x 3240 up to 80 fps [560 Mb/s] 5120 x 2700 up to 96 fps [560 Mb/s] 4096 x 2160 up to 120 fps [560 Mb/s] 2048 x 1080 up to 240 fps [560 Mb/s]
External Recording Modes	4:2:2 via SDI/BNC DCI 4K (4096 x 2160) up to 60.00 fps DCI 2K (2048 x 1080p) up to 60.00 fps
Fast-/Slow-Motion Support	Yes
Built-In Microphone Type	Stereo
Audio Recording	2-Channel 24-Bit 48 kHz
IP Streaming	MJPEG 1920 x 1080 (5000.00 Mb/s)

Interface

Media/Memory Card Slot	Single Slot: CFexpress Type B (CFexpress 2.0)
Video I/O	1 x BNC (12G-SDI) Output
Audio I/O	1 x LEMO 5-Pin Line Input on Camera Body
Power I/O	1 x LEMO 6-Pin (11 to 17VDC) Input
Other I/O	1 x 9-Pin (Genlock, GPI, Timecode) 1 x USB-C (Camera Interface) Control/Data/Video Input/Output 1 x RED Cable-Free Monitor Connection Output
Wireless	2.4 / 5 GHz Wi-Fi 5 (802.11ac) Video Output, Control
Mobile App Compatible	Yes: Android & iOS App Name: RED Control Functionality: Remote Control *As of January, 2023: Check with manufacturer for the most up-to-date compatibility
Global Positioning (GPS, GLONASS, etc.)	None

Monitor

Display Size	2.9"
Resolution	1440 x 1440
Display Type	Fixed Touchscreen LCD

Viewfinder

Type	Optional, Not Included

Focus

Focus Type	Auto and Manual Focus
Focus Mode	Automatic, Manual Focus

Environmental

Operating Temperature	32 to 104°F / 0 to 40°C
Storage Temperature	-4 to 122°F / -20 to 50°C
Storage Humidity	0 to 85% (Non-Condensing)

General

Battery Type	V-Mount
Tripod Mounting Thread	1/4"-20 Female (Bottom) 3/8"-16 Female (Bottom)
Accessory Mounting Thread	4 x 1/4"-20 4 x M4
Material of Construction	Aluminum
Dimensions (W x H x D)	5.09 x 3.99 x 3.75" / 129.37 x 101.26 x 95.26 mm
Weight	2.62 lb / 1.19 kg (Body Only)
