Shure Uniplex UL4-LM3 Микрофон брошка кардиод cocoa
Free delivery to Econt office
for orders over 100 BGN
Please fill your E-mail address where you want to receive the availability notification for Shure Uniplex UL4-LM3 Микрофон брошка кардиод cocoa or your contact phone number.
-
The Shure UniPlex UL4 is a professional subminiature cardioid lavalier microphone that is ideal for speech applications in broadcast, corporate, and conference environments. The subminiature design and custom cardioid element provide robust audio performance. Each microphone is supplied with a storage pouch, single tie clip, and snap-fit windscreen.
Features
- 5 mm cardioid subminiature design for discrete placement
- 1.6 mm PLEX Cable technology, paintable cable, and no memory effect
- Professional sound quality for speech applications
- High RF immunity, compatible with Shure digital wireless systems without RF interference
- Included case, tie clip, and windscreen
- TA4F and LEMO terminations for variable wireless system connectivity
- Available in Black, Tan, Cocoa, and White finishes
-
Note: Only use UL4 with Shure wireless systems
-
MTQG -42 dBV/Pa [1] LEMO -37 dBV/Pa [1] Self-Noise, A-Weighted, Equivalent Acoustical
MTQG 32 dB SPL-A LEMO 32 dB SPL-A Signal-To-Noise Ratio [2]
MTQG 62 dB-A LEMO 62 dB-A Maximum SPL [3]
130 dB SPL,1 kHz at 1% THD, typical
Dynamic Range
98 dB typical
Microphone Current Draw
530 µA, maximum
Bias Voltage
Recommended Operating Voltage
3.5-5 V DC minimum, 5.5 V DC maximum
Housing
Molded ABS
Polarity
MTQG Positive pressure on the diaphragm produces positive voltage on pin 3 with respect to pin 1 LEMO Positive pressure on the diaphragm produces positive voltage on pin 3 with respect to pin 1 Cable Diameter
1.6 mm
Cable Length
66 in. (1.67 m)
Net Weight
12.5 g (0.44 oz.)
[1] 1 Pa=94 dB SPL
[2] S/N ratio is the difference between 94 dB SPL and equivalent SPL of self noise, A-weighted
[3] THD of microphone preamplifier when applied input signal level is equivalent to cartridge output at specified SPL
| Bag | No |
| Connector | 3.5mm stereo |
| Highest frequency | 20000 Hz |
| Lowest Frequency | 40 Hz |
| Max. SPL | 130 dB |
| Polar Pattern | Cardioid |
| Type capsule | Condenser |
| Type microphone | Tie-clip |
| Warranty | 24 months |
Package weight: 0.06 kg
-
